TZD Bulk Grain Silo Bucket Elevator

HOME > PRODUCTS > Conveying Equipment > Bucket Elevator >

We are a Conveying Equipment manufacturer in China With rich experience in TZD Bulk Grain Silo Bucket Elevator, with Competitive price and top quality.

TZD bulk grain silo bucket elevator is specially designed according to the needs of China's ports and large and medium-sized grain warehouses.

CONTACT

Product details

Product parameters

Product details

TZD bulk grain silo bucket elevator is specially designed according to the needs of China's ports and large and medium-sized grain warehouses. This series of bucket elevator adopts double channel shell, with high speed, large lifting height, large conveying capacity and stable operation. There are 8 types of bucket elevator in this series.

Model		TZD200	TZD250	TZD300	TZD400	TZD500	TZD650	TZD800	TZD1000
Capacity (t/h)		50~80	80~120	150~210	200~300	350~400	380~450	500~650	700~800
Bucket	Speed (m/s)	2~3.1	2~3.1	2.5~3.5	2.5~3.5	3.2~3.9	3.2~3.9	3.2~4.0	3.2~4.0
	Bucket volume (L)	1.21	2.35	6	8.4	10.9	2X6	2×8.4	2×10.9
	Bucket spacing (mm)	105	125	215	215	215	215	215	215
	Bucket width (mm)	186	238	280	380	380	2X280	2X380	2X480
Belt width (mm)		200	250	300	400	500	650	800	1000
Diameter of head roller (mm)		630	630	710	710	710	800	1140	1140
